    Hollow Shaft Conductive Slip Rings Collector with ID12mm For Industrial System

    Ask Lasest Price
    Brand Name : CENO
    Model Number : ECN012-06P2-18P1
    Certification : CE,RoHS,ISO9001,UL
    Price : Negotiable
    Payment Terms : T/T,Paypal, Western Union
    Supply Ability : 500pcs per month
    Delivery Time : 1 week
    • Product Details
    • Company Profile

    Hollow Shaft Conductive Slip Rings Collector with ID12mm For Industrial System

    Hollow Shaft Conductive Slip Rings Collector with ID12mm For Industrial System


    ECN012-06P2-18P1 is CENO Conductive Slip Ring with inner bore 12mm for industrial system. The slip ring as an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure, often called a rotary electrical joint joint, collector or electric swivel, and can be used in any electromechanical system where requires unrestrained, intermittent or continuous rotation while transmitting power or data. More information please contact us.



    Specification

    ECN012-06P2-18P1

    Specification
    Current & Circuits18 Circuits * 2A; 6 circuits *10A;
    Rating Voltage0-380VAC/VDC
    Dielectric strength≥1000VAC@50Hz
    Isolation resistance≥500MΩ@500VDC
    Contact resistance30mΩ (50rpm)
    Contact materialPrecious Metal
    Housing materialAluminum Alloy
    Working temperature-20°C~+60°C
    Working humidity60 %RH
    IP protection gradeIP51
    Operating speed0~300rpm
    Inner diameter12.7mm
    Lead wire size

    AWG17# 24# Wire Teflon® UL

    2 cores Twisted Shielded wire

    Lead wire lengthRotor : 300mm; Stator : 300mm
    Rotation WayRotor side fixed on customer main shaft with screws

    Features

    • Through hole design 3-1000mm
    • Wide operating temperature envelop and speed range
    • Can be integrated various data
    • Install easy & Free maintenance

    Applications

    • Automatic machine
    • Turntable testing machine
    • Robot
    • Medical equipment
    • Mines

    Optional

    • Circuit, Voltage, Current
    • Inner / outer diameter
    • Contact / Housing Materials
    • Protection grade
    • Working speed

    Outline drawing


    Our Service

    1. Reply inquiry in 24 hours.

    2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.

    3. Answer your question detailed.

    4. Solved the problem with you during using our products.

    5. Samples will be offered to you for our future cooperation.


    FAQ

    1. What do we do?

    We focus on developing, designing, manufacturing high quality sliprings, and offer various solutions for rotating systems.


    2. How long have we been in the business?

    CENO established slip rings business since 2009. We have thousands of customers accepted our products or services.


    3. What is a slip ring?

    A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints.


    4. How do I choose a slip ring?

    Proper selection of a slip ring solution requires details about your application’s operating parameters including total circuits, voltage and amps per circuit, operating speed, and mounting type. A good place to start your search is with our standard slip rings. If you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started.


    5. Do you offer custom slip rings?

    Yes, if you are confident that a custom / modified solution is most likely required or need assistance in your selection, contact us to Get Started. Our engineers will come up with perfect solution for your needs.


    Why with CENO


    CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.

    10MPa air rotary union 2 channel air 6 circuits 5Amp power integral slip ring


    Certification

    ISO9001,CE,RoHS,UL,Explosion-proof

    Single channel fiber optic rotary joint 6.8mm OD stainless steel


    CENO Advantage

    Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.


    Service CENO provides

    24 hours,7days consultant service.

    Mass and customized production.

    Solution offerring for 360° rotation system.


    Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
