    100m Ethernet Signal Electrical Capsule Slip Rings Mini 22mm For Medical Equipment

    Ask Lasest Price
    Brand Name : CENO
    Model Number : ACN22-12S-01EM 100M
    Certification : CE,RoHS,UL,ISO9001
    Price : Negotiable
    Payment Terms : T/T,Paypal,Western Union, L/C
    Supply Ability : 10000pcs month
    Delivery Time : Off the shelf
    • Product Details
    • Company Profile

    100m Ethernet Signal Electrical Capsule Slip Rings Mini 22mm For Medical Equipment

    100M Ethernet Signal Mini Slip Ring Capsule external diameter Ø22mm for medical equipment


    ACN22-12S-01EM is a new miniature slip ring capsule with 13 circuits for 100M Ethernet and signals which designed for medical equipment. CENO economical compact slip ring capsule family allow tremendous flexibility in dealing with system size requirements when large versions are not an option. Mini slip ring capsule with up to 125 circuits are available. Support many kinds of data, signal combined power transmission. Always apply to the drones, traffic system, turret on a vehicle etc, for more information about CENO miniature slip ring, please contact us freely.


    Features

    u 1,2,3...125 circuits optional

    u Small compact structure with military grade surface treatment

    u Install easily & transmit stably & can integrated various data

    Applications

    u Solar trackers

    u LED automatic equipment

    u Drones

    u Robotics

    u Medical equipment

    Optional

    u Circuits, Voltage, Current

    u Data & signal types

    u Contact / Housing Materials

    u Protection grade

    Lead wire size & length



    Specification

    ACN22-12S-01EM

    Specification
    Current & Circuits1circuit*100M Ethernet; 12circuits*2A
    Rating Voltage0~240VAC/VDC
    Dielectric strength≥500VAC@50Hz; ≥100VAC@50Hz
    Isolation resistance≥100MΩ@500VDC; ≥10MΩ@100VDC
    Contact resistance≤35mΩ (50rpm)
    Contact materialGold - Gold
    Housing materialEngineer Plastic
    Working temperature-40°C~+60°C
    Working humidity≤60%RH
    Protection GradeIP40
    Operating speed0~100rpm

    Lead wire length

    Rotor:1000mm±20mm; Stator:900mm±20mm
    External diameterØ22mm

    Outline drawing


    Support and Services:

    Capsule Slip Ring Technical Support and Service

    We provide technical support and service for our Capsule Slip Ring products. Our team of experts is available to assist you with any questions you may have about the product, its installation, its use and maintenance. We also offer troubleshooting and repair services if the product requires it. If you need to replace any parts of the product, we can provide them to you quickly and at a competitive price.

    We also provide regular maintenance and inspection services for our Capsule Slip Ring products. This helps to ensure that the product is functioning properly and that it is in good condition. We also provide warranty coverage for our products, so you can rest assured that your purchase is protected.

    Our customer service team is available to answer any questions you may have about our Capsule Slip Ring products. We are dedicated to providing the best possible support and service for our customers, and we look forward to hearing from you.

    FAQ:

    Q1. What is CENO Capsule Slip Ring?
    A1. CENO Capsule Slip Ring, model number CCN-10J, is a rotary electrical connector, which can transmit power and signal from a stationary structure to a rotating one.
    Q2.Where is CENO Capsule Slip Ring made?
    A2. CENO Capsule Slip Ring is made in China.
    Q3.What certifications do CENO Capsule Slip Ring have?
    A3. CENO Capsule Slip Ring is certified by CE,RoHS,UL,ISO9001.
    Q4.What is the minimum order quantity of CENO Capsule Slip Ring?
    A4. The minimum order quantity of CENO Capsule Slip Ring is 1.
    Q5.What is the delivery time of CENO Capsule Slip Ring?
    A5. CENO Capsule Slip Ring is off the shelf and can be delivered quickly.
