    Aluminum Alloy 1310Nm 1550 Nm Fiber Optic Rotary Joint With SM Connector

    Ask Lasest Price
    Brand Name : CENO
    Model Number : ECN000-02P3-01F
    Certification : CE,RoHS,ISO9001,UL
    Price : Negotiable
    Payment Terms : T/T,Paypal, Western Union
    Supply Ability : 500pcs per month
    Delivery Time : 1 week
    • Product Details
    • Company Profile

    Aluminum Alloy 1310Nm 1550 Nm Fiber Optic Rotary Joint With SM Connector

    Aluminum Alloy 1310Nm 1550 Nm Fiber Optic Rotary Joint With SM Connector


    Stable performance fiber optic rotary joint with SM connector,wavelength 1310/1550 nm,aluminum alloy housing,working speed 0-1000 rpm,Widely used for medical equipment,inspection instrument,rotary tables etc.


    This unit can be used in any electromechanical system that requires unrestrained,continuous rotation while transferring power or data from a stationary to a rotating structure.It can provide high speed,long life,high protection slip ring customization,and integrate a variety of signals,such as Ethernet,USB,RS,CANbus, FireWire,SDI,HDMI,etc.ECN000-02P3-01F with compact power and signal handling design provides unique capability for many challenging applications.also provide smoother running,higher design precision, lower torque,lower contact resistance,and lower electrical noise than competitive slip rings.CENO also provide special design according to customer's requirements,please contact with us if you have any project about slip ring ,we will reply you as soon as possibile.


    Specification


    Specification
    Circuits & Current2*12A,1*fiber optic
    Voltage0-400VAC/VDC
    Dielectric strength≥1000V@50Hz
    Insulation resistance≥500MΩ@50VDC
    Electrical noise≤30mΩ (50 rpm)
    Operating speed0-1000 rpm
    Contact materialPrecious metal
    Housing materialAluminum alloy
    IP gradeIP51
    Fiber channel & type1 channel SM
    Wavelength1310/1550 nm

    Features

    • Power integrated fiber optic
    • High working speed
    • Flange installation
    • Wavelength 1310/1550nm
    • Fiber type SM

    Applications

    • Medical equipment
    • Inspection instrument
    • Rotary tables
    • Test benches

    Optional

    • Circuits number
    • IP protection grade
    • Fiber optic type
    • Signal type & current rating
    • Wavelength

    Outline drawing



    Our Service

    1. Reply inquiry in 24 hours.

    2. Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.

    3. Answer your question detailed.

    4. Solved the problem with you during using our products.

    5. Samples will be offered to you for our future cooperation.


    Why with CENO

    CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.

    10MPa air rotary union 2 channel air 6 circuits 5Amp power integral slip ring


    Certification

    ISO9001,CE,RoHS,UL,Explosion-proof

    Single channel fiber optic rotary joint 6.8mm OD stainless steel


    CENO Advantage

    Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.
