    690VAC Crane Slip Ring Safely Current Carrying Capacity IP 56 Protection Grade

    Ask Lasest Price
    Brand Name : CENO
    Model Number : BHCN-10P-20P3-02P2-09S
    Certification : CE,RoHS,ISO9001,UL
    Price : Negotiable
    Payment Terms : T/T,Paypal, Western Union
    Supply Ability : 1000pcs per month
    Delivery Time : 1 weeks
    • Product Details
    • Company Profile

    690VAC Crane Slip Ring Safely Current Carrying Capacity IP 56 Protection Grade

    690VAC Carbon Brush Slip Ring Safely Current Carrying Capacity


    CENO's carbon Brush slip ring is also named as large current collector or high power slip ring, which could transmit the current at lease on 100A or above. It widely be used in ship machinery, engineering machinery, port machinery, offshore crane, cable reel, propeller,as well as drilling platform.


    Features

    • Safely current carrying capacity
    • Long lifespan, maintenance-free
    • Various type of signal could be integrated

    Applications

    • Marine crane
    • Propulsion
    • Drill crane

    Optional


    • IP protection grade
    • Current rating
    • Signal type

    Specification


    Parameter
    Current

    3*550A(690VAC),3*80A(230VAC),3*50A(480VAC),

    20*15A,2*10A,9*signal

    Protection gradeIP56
    Rating voltage690VAC/480VAC/230VAC/24VACWorking temperature-10℃~+55℃
    Resistance insulation500MΩ@500VDC,300MΩ@100VDCWorking Humidity<90%RH
    Dielectric strength≥1000VAC@60HzWorking rotating0~1rpm
    Resistance fluctuation≤70mΩContact materialCopper graphite,silver-coated brush

    Outline drawing





    Why with CENO

    CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.



    Certification

    ISO9001,CE,RoHS,UL,Explosion-proof

    Single channel fiber optic rotary joint 6.8mm OD stainless steel


    CENO Advantage

    Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.


    Service CENO provides

    24 hours,7days consultant service.

    Mass and customized production.

    Solution offerring for 360° rotation system.


    Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
